Leadex70

Description

The Leadex70 is designed for all intraoral dental radiology requirements in the modern dental practice. Integrated directly on your Ritter dental unit, the Leadex70 is a flexible, fast and safe solution to produce an excellent small X-ray image. Compatible with standard films and digital X-ray sensors, it guarantees sharp and high-contrast images at an attractive price. The control unit is easy and intuitive to use. It can be mounted directly on the wall in the treatment room or in an adjacent room (cable from the unit in the floor). The X-ray process is performed via the control panel or via the supplied remote control unit.

TECHNICAL DATA
Alternating current AC Direct current DC
Supply voltage: 115V; 220V; 230V ±10% 230V; 115V ±10%
Mains frequency: 50/60Hz 50/60Hz
Impedance of the line: 0.5 Ohm; 0.2 Ohm 0.5 Ohm; 0.2 Ohm
Rated current: 3,5A; 5,7A 5,2A; 9,5A
Fuse: F 8A-250V; F 12,5A-250V F 8A-250V; F 12,5A-250V
Size of the focal spot: 0.7 0.7
Plug connection: Coaxial connector Like AC
Nominal high voltage: 70kV 60/70kV
Nominal anode current: 8mA 4mA/8mA
Work cycle: 1:32 1:32
Total filtration: 2.3mm Al 2.4mm Al
Half-layer: 2,0mm Al@70 kV 2,2mm Al@70 kV
Scattered radiation: <0,25 mGy/h <0,25 mGy/h
Exposure time: 0,08–3,2s (17 Steps) 0,02–3,2s (23 Steps)
Total weight: 19,5kg 19,5kg
Beam limiting device (AC and DC)
Output: round; rectangular
Focus-skin distance: 20 cm; 31 cm
Fastening system: Wall/mobile/on unit
Extension arms: 41, 82 und 110 cm
Usable range: 143 cm with 41 cm external arm; 184 cm with 82 cm external arm; 212 cm with 110 cm external arm
